Smart SFP

A smart SFP is a network interface module that is inserted into network and voice communication equipment. The benefit of an SFP port is that it enable equipment to support a wide variety of media and connection types(fiber, copper,etc.)such as TDM over Packet, migration and integration of Transport Networks into Packet Switching Networks, interoperability with any standard SAToP equipment, and aggregation of SONET/SDH links.  All Smart SFP transceivers are compliant with MSA recommendations and can be hot plugged and hot swapped.
Ordering Information
Features
Application
Part No.ProductData Rate(bps)WavelengthMediaReachConnectorTemp.
GTS-T0001-01-ISTPOP E12MN/ACAT.5100mRJ-45 -40~85
GTS-T0001-04-ISTPOP E11.5MN/ACAT.5400mRJ-45 -40~85
GTS-COAX3-14-ISCPoP T345MN/ASMF1kmMini Coax -40~85
GTS-L1325-02-CSEOS OC-48/STM-162.5G1310nmSMF2kmDuplex 0~70
GTS-L1306-40-ISTSOP OC-12/STM4622M1310nmSMF40kmDuplex -40~85
GTS-L1306-80-ISTSOP OC-12/STM4622M1310nmSMF80kmDuplex -40~85
GTS-L1303-15-ISTSOP OC-3/STM1155M1310nmSMF15kmDuplex -40~85
GTS-L1303-40-ISTSOP OC-3/STM1155M1310nmSMF40kmDuplex -40~85
GTS-L1303-80-ISTSOP OC-3/STM1155M1310nmSMF80kmDuplex -40~85
GTS-L1312-10-ISEthernet OAM GE1.25G1310nmSMF10kmDuplex -40~85
GTS-L1312-20-ISEthernet OAM(64MEP) GE1.25G1310nmSMF20kmDuplex -40~85
GTS-L1312-40-ISEthernet OAM(64MEP) GE1.25G1310nmSMF40kmDuplex -40~85
GTS-L1312-80-ISEthernet OAM(64MEP) GE1.25G1310nmSMF80kmDuplex -40~85
GTS-B1312-10-ISEthernet OAM GE1.25G1310nmSMF10kmSimplex LC -40~85
GTS-B1312-20-ISEthernet OAM(64MEP) GE1.25G1310nmSMF20kmSimplex LC -40~85
GTS-B1312-40-ISEthernet OAM(64MEP) GE1.25G1310nmSMF40kmSimplex LC -40~85
GTS-B1312-80-ISEthernet OAM(64MEP) GE1.25G1310nmSMF80kmSimplex LC -40~85
GTS-L1312-10-ISxIP OAM GE1.25G1310nmSMF10kmDuplex -40~85
GTS-L1303-15-ISaCSOP (STM-1)63.E1155M1310nmSMF15kmDuplex -40~85
GTS-L1303-15-ISxCSOP (OC-3)84.T1155M1310nmSMF15kmDuplex -40~85
GTS-COAX3-14-ISxVCOP T345MN/ASMF1kmMini Coax -40~85
GTS-L1325-02-CSxTSOP OC-48/STM-162.5G1310nmSMF2kmDuplex 0~70

Features

  • SFP INF-8074 compatible
  • DDM SFF-8472 compliant
  • Software API for remote management
  • Remote access to Digital Diagnostics Monitoring
  • Link OAM IEEE 802.3ah
  • CFM Service OAM IEEE 802.1ag
  • ITU-T Y.1731 Performance Management
  • Transparent to Synchronous Ethernet
  • Link Pass Through a.k.a. Link Loss Forwarding
  • Low latency and wire speed GbE throughput
  • Protocol processor for OAM

Application

  • Appliance for IP SLA agent
  • IP SLA Probe
  • Smart Loopback
  • SFP with integrated OTDR
  • 3-port Ethernet switch
  • Precision network time server(PTP grandmaster clock)
  • 5G/4G USB router
  • uCPE
